Side Mount Kits for Cabinet Panel Coolers

Side Mount Kits for Cabinet Panel Coolers

Applications

  • The Side Mount is attached on the side of a cabinet but as near the top as possible so that the Panel Cooler can fit into the limited space they have.
  • The hose distribution kit, which distributes cold air from the Panel Cooler, is easily connected to the brass tube with the hose clamp supplied, in the same way as if connected to the Panel Cooler normally.

Advantages & Benefits

The Side Mount is attached on the side of a cabinet but as near the top as possible so that the Panel Cooler can fit into the limited space they have. It is attached through a standard electrical knockout and secured in place with a lock ring. The Panel Cooler is then threaded into the outside top of the side mount which has a brass tube at the exit, on the inside of the control panel that is the same size as the one on the Panel Cooler.

The hose distribution kit, which distributes cold air from the Panel Cooler, is easily connected to the brass tube with the hose clamp supplied, in the same way as if connected to the Panel Cooler normally. Then the hose kit is strung around the inside of the control panel with holes drilled to direct the cold air onto the hot spots as required.
